10 13 15 Inch FPV Drone 5kg-8kg Payload Racing Drone 20km Flight Distance
| MOQ: | Negotiable |
| Price: | Negotiable |
| Standard Packaging: | Carton Case |
| Delivery Period: | 7 - 15 working Days |
| Payment Method: | T/T, Western Union, MoneyGram |
| Supply Capacity: | 60000 Unit/Units per Month |
Detail Information
Place of Origin
China
Maximum Take-off Altitude:
5000 Meters
Maximum Speed:
130 KM/H
Maximum Flight Distance:
20km
Rated Load:
7000g
Maximum Load:
8000g
Maximum Take-off Weight::
13000g
No-load Endurance Time:
42 Min (8s 8000mah*2,4.9kg)
Rated Load Endurance Time:
12 Min (8s16000mah,11.8kg)
Highlight:
15 Inch FPV Drone
,8kg Payload Racing Drone
,20km FPV Drone
Product Description
10/13/15 Inch FPV Drone with 5-8kg Payload and 20km Flight Distance
Key Specifications
| Attribute | Value |
|---|---|
| Maximum take-off altitude | 5000 meters |
| Maximum speed | 130 KM/H |
| Maximum flight distance | 20km |
| Rated load | 7000g |
| Maximum load | 8000g |
| Maximum take-off weight | 13000g |
| No-load endurance time | 42 min (8s 8000mah*2,4.9kg) |
| Rated load endurance time | 12 min (8s16000mah,11.8kg) |
Product Features
- First-person perspective (FPV) operation for immersive control
- High-performance 4214 motor for efficient power delivery
- Exceptional flight stability and maneuverability
- Extended range capability with 20km maximum flight distance
- High-altitude operation up to 5000 meters
- Heavy payload capacity from 5kg to 8kg
Technical Details
Net Weight:
2080g
Frame:
15Inch frame
Wheelbase:
647mm
Size:
517×517×80mm
Material:
3K T300 carbon fiber
Flight Control:
DV BL F405 (optional)
ESC:
DV 80A single ESC
Image Transmission:
DV 5.8G 3W image transmission (optional)
Camera:
DV1800TVL night vision FPV camera (optional)
Motor:
DV 4214 380KV
Propeller:
1507 (glass fiber nylon)
Recommended Battery:
8S 8000 10-50C XT60 plug×2
Performance Highlights
Maximum Speed:
130 KM/H
Payload Capacity:
5-8kg
Flight Distance:
20km
